WTHD 3KW AC Solar Inverter Pure Sine Wave 100A 500VDC off Grid 24V MPPT Hybrid Single >94% Efficiency 4200W Max PV Input

WTHD 3KW AC Solar Inverter Pure Sine Wave 100A 500VDC off Grid 24V MPPT Hybrid Single >94% Efficiency 4200W Max PV Input

₱13,019.08PHP
₱13,019.08PHP
ApplicationOff-Grid Solar System
Output Power3 kW
Inverter TypeString Inverter

SPECIFICATIONS

Brand Name: WTHD

Certificate: EN-IEC 60335-1,EN-IEC 60335-2-29.IEC 62109-1

Controller Type: MPPT

Input Voltage: 220/230/240VAC

Inverter Efficiency: >94%

Maximum AC charging current: 100A

Maximum PV Voltage: 500VDC

Model Number: WTHD-HI-3K/24V

Output Current: Dependent on connected load and conditions

Output Frequency: 50/60Hz±0.1%

Output Type: Single

Output Voltage: 220/230/240VAC±5%

PV maximum input power: 4200W

Place of Origin: Guangdong, China

Product name: AC Solar Inverter

Size: 495*312*146mm

Type: DC/AC Inverters

Warranty: 1 year

Waveform: Pure Sine Wave

Weight: 6.48KG

Working Temperature: -10℃~50℃

3KW Ac Solar Inverter pure sine wave 3000 watt off grid 3Kva 3000w 24v mppt hybrid solar power inverter
Product Paramenters
Model
WTHD-HI-3K/24V
WTHD-HI-3.6K/24V
WTHD-HI-5.5K/48V
WTHD-HI-6.2K/48V
Input Formation
L+N+PE
AC Input
220/230/240VAC
Input Voltage Range
90-280VAC±3V(Normal Mode)185-264VAC±3V (UPS Mode)
Frequency
50/60Hz(Adaptive)
Rated Power
3000W
3600W
5500W
6200W
Output Voltage
220/230/240VAC±5%
Output Frequency
50/60Hz±0.1%
Output Wave
Pure Sine Wave
Transfer Time(Adjustable)
10ms for Computer Equipment,20ms for Household Equipment
Peak Power
6000VA
7200VA
11000VA
12400VA
Overload Ability
Battery Mode∶21s@105%~150% load 11s@150%~200% load 400ms@>200% load
Peak Efficiency
(Battery Model)
>94%
Rated Voltage
24VDC
48VDC
Constant Charging Voltage
28.2VDC
56.4Vdc
Float Charging Voltage
27VDC
54VDC
PV Charging Method
MPPT
Max PV Input
4200W
4200W
5500W
6200W
MPPT Tracking Range
120~500VDC
120~500VDC
120~500VDC
120~500VDC
MAX PV Input Voltage
500VDC
500VDC
500VDC
500VDC
MAX PV Charge Current
100A
100A
100A
100A
MAX AC Charge Current
60A
80A
60A
80A
MAX Charge Current
100A
120A
100A
120A
LCD
Can display operating mode/load/input/output
RS232
5PIN/Pitch2.54mm,Baud Rate 2400
Expansion Slot Communication

Lithium Battery BMS Communication Card,WIFI 2×5PIN/Pitch2.54mm
Interface
Parallel Interface
Not Support Parallel
Support Parallel
Operating Temperature
0℃~40℃
Storage Temperature
-15℃~60℃
Ork Altitude
No more than 1000m, If 1000m<,Rate power will lower, MAX 4000m, Refer
Operating Environment Humidity
Non Condensing
Noise
<50dB
L*W*H(mm)
495*312*146mm
Standards and Certifications
EN-IEC 60335-1,EN-IEC 60335-2-29.IEC 62109-1
