SPECIFICATIONS

Brand Name: Solis

Input Voltage: 187-253 V

Inverter Efficiency: 99.8%

Model Number: S6-EH1P(3-8)K-L

Output Current: 63.6 A / 60.9 A

Output Frequency: 45-55 Hz/55-65 Hz

Output Type: Single

Output Voltage: 220 V / 230 V

Place of Origin: Guangdong, China

Size: 464*763*282 mm

Type: ac-dc-ac

Weight: 48.5kg

Product Description

Models	3kw	6kw	8kw
Recommended max. PV array size	6kw	12kw	16kw
Max. input voltage	550V
Rated voltage	380V
Start-up voltage	100V
MPPT voltage range	80-520 V
Max. input current	40 A / 40 A / 40 A
Max. short circuit current	50 A / 50 A / 50 A
MPPT number/Max. input strings number	3/6
Battery type	Li-ion / Lead-acid
Battery voltage range	40 - 60 V
Max. charge / discharge power	3KW	6KW	8KW
Operation phase	220 V / 230 V
Rated grid output current	54.5 A / 52.2 A	63.6 A / 60.9 A	72.7 A / 69.6 A
Max. output current	54.5 A / 52.2 A	63.6 A / 60.9 A	72.7 A / 69.6 A
Input voltage range	187-253 V
Frequency range	45-55 Hz/55-65 Hz
Max. apparent output power	2 times of rated power, 10 s
Rated output current	54.5 A / 52.2 A	63.6 A / 60.9 A	72.7 A / 69.6 A
Max. output over current protection, 10 sec	109 A	127 A	145 A
Max. input current	54.5 A	63.6 A	72.7 A
Dimensions (W*H*D)	464*763*282 mm
Weight	48.5 kg
Grid connection standard	NRS 097-2-1, IEC 62116, IEC 61727, IEC 60068, IEC 61683, EN 50530
Communication	RS485, Optional: Wi-Fi, LAN
