DDP EU BYD All in One Solar 12Kw Inverter and Lithium Battery System 15Kwh 20kwh 30Kwh 50Kwh 60Kwh 51.2V Battery Energy Storage
12KW inverter / White / 10 kW
₱58,947.49PHP
Sale price
₱58,947.49PHP
Regular price
Skip to product information
DDP EU BYD All in One Solar 12Kw Inverter and Lithium Battery System 15Kwh 20kwh 30Kwh 50Kwh 60Kwh 51.2V Battery Energy Storage
₱58,947.49PHP
Sale price
₱58,947.49PHP
Regular price
Pickup currently not available
SPECIFICATIONS
BMS Discharge Cut-off Voltage: 40V
Battery Type: LiFePO4,3.2V 300Ah LiFePO4 Battery
Brand Name: delongtop
Charge Current: 0.2C~0.5C
Charge Model: CC/CV
Communication Port: CAN
Cycle Life: 6500 Times
Dimension (L*W*H): 690*590*258mm
Discharge Current: 1C
Energy: 15kwh
Grid connection: Off grid
Model Number: LFP51300
OEM/ODM: Accepatable
Output Power Range: 10-20Kw
Place of Origin: Guangdong, China
Product Name: 48V 300Ah LiFePO4 Battery Pack
Protection Class: IP54
System Type: Rack-mounted
System Voltage: 51.2 V
Type: All-In-One
Warranty: 10 Years
Weight: 130kg
Why Choose Delong Energy
At Delong Energy, we are your trusted one‑stop supplier for solar hybrid inverters, lithium‑ion batteries, and integrated energy
storage solutions. With over 13 years of R&D and manufacturing experience, we focus on safe, stable, and high‑efficiency energy
products for global residential, commercial, and off‑grid applications.
We use premium Grade A LiFePO4 cells and intelligent BMS protection to ensure long cycle life, high safety, and stable output. All
products pass strict quality inspections and hold international certifications including CE, ISO, IEC, MSDS, and UN38.3, fully
compliant with global customs and market standards.
As a professional factory, we provide competitive factory direct prices, stable mass production, and flexible OEM/ODM
customization, including voltage, capacity, communication protocol, and appearance design. Our technical team supports fast
response, on‑site guidance, and complete after‑sales service to help you reduce costs and improve system reliability.
We commit to reliable quality, on‑time delivery, and long‑term partnership. Choosing Delong Energy means choosing stable power,
safer energy storage, lower total cost, and worry‑free global service.
At Delong Energy, we are your trusted one‑stop supplier for solar hybrid inverters, lithium‑ion batteries, and integrated energy
storage solutions. With over 13 years of R&D and manufacturing experience, we focus on safe, stable, and high‑efficiency energy
products for global residential, commercial, and off‑grid applications.
We use premium Grade A LiFePO4 cells and intelligent BMS protection to ensure long cycle life, high safety, and stable output. All
products pass strict quality inspections and hold international certifications including CE, ISO, IEC, MSDS, and UN38.3, fully
compliant with global customs and market standards.
As a professional factory, we provide competitive factory direct prices, stable mass production, and flexible OEM/ODM
customization, including voltage, capacity, communication protocol, and appearance design. Our technical team supports fast
response, on‑site guidance, and complete after‑sales service to help you reduce costs and improve system reliability.
We commit to reliable quality, on‑time delivery, and long‑term partnership. Choosing Delong Energy means choosing stable power,
safer energy storage, lower total cost, and worry‑free global service.
Product Description
Battery Specification LFP51300 Series module can easily expand the capacity to 80kwh
|
48V |
|||||
Parameters |
LFP51300A |
LFP51300B |
LFP51300C |
|||
Model |
LFP51300A |
LFP51300B |
LFP51300C |
|||
Nominal Voltage |
51.2V |
51.2V |
51.2V |
|||
Nominal Capacity |
280Ah |
305Ah |
314Ah |
|||
Battery Modules |
1/2/3/5 |
1/2/3/5 |
1/2/3/5 |
|||
System Nominal Energy |
14.33KWh / 28.67KWh / 43.0KWh / 71.68KWh |
15.61KWh / 31.23KWh / 46.84KWh / 78.08KWh |
16.07KWh / 32.15KWh / 48.23KWh / 80.38KWh |
|||
Discharging Cut-off Voltage |
44.8V±0.2V |
44.8V±0.2V |
44.8V±0.2V |
|||
Charging Cut-off Voltage |
57.6V±0.2V |
57.6V±0.2V |
57.6V±0.2V |
|||
Charging Current |
Recommend / 40A; Max. / 100A* |
Recommend / 40A; Max. / 100A* |
Recommend / 40A; Max. / 100A* |
|||
Discharging Current |
Recommend / 100A; Max. / 200A* |
Recommend / 100A; Max. / 200A* |
Recommend / 100A; Max. / 200A* |
|||
Peak Discharging Current |
205A(5 sec.)* |
205A(5 sec.)* |
205A(5 sec.)* |
|||
Nos of Cells |
16pcs (Single battery module) |
16pcs (Single battery module) |
16pcs (Single battery module) |
|||
Weight |
≈118±0.5Kg (Single battery module) |
≈118±0.5Kg (Single battery module) |
≈118±0.5Kg (Single battery module) |
|||
Dimensions(LWH) |
690590258/388mm (Single battery module) |
690590258/388mm (Single battery module) |
690590258/388mm (Single battery module) |
|||
Cell Type |
LiFePO4 Battery |
LiFePO4 Battery |
LiFePO4 Battery |
|||
Terminal |
M8 |
M8 |
M8 |
|||
Case Material |
Metal Box |
Metal Box |
Metal Box |
|||
Communication Mode |
RS485/CAN |
RS485/CAN |
RS485/CAN |
|||
Depth of Discharge |
95 |
95 |
95 |
|||
Working Temperature |
0°C~50°C Charge / -10°C~50°C Discharge |
0°C~50°C Charge / -10°C~50°C Discharge |
0°C~50°C Charge / -10°C~50°C Discharge |
|||
The Shelf Temperature |
-20°C~60°C |
-20°C~60°C |
-20°C~60°C |
|||
Humidity |
5~95%(RH) |
5~95%(RH) |
5~95%(RH) |
|||
Design Life Cycle |
10+Years (25°C/77°F) |
10+Years (25°C/77°F) |
10+Years (25°C/77°F) |
|||
Cycle Life |
≥6500 at 25°C |
≥6500 at 25°C |
≥6500 at 25°C |
|||
You can take our 12Kw inverter, This is All in one Ess system. easily to intall: This 12KW solar hybrid off grid inverter integrates advanced inverter technology, dual MPPT solar charge controller, and battery management system into one compact unit. Designed for residential, commercial and off-grid power systems, it supports both on-grid and off-grid working modes, providing stable, efficient and reliable power supply for home energy storage, backup power and daily
electricity use. |
Parameter |
|
Model |
SPI48-DL10K |
|
AC Mode |
||
Rated input voltage |
230Vac ±5% |
|
Input voltage range |
(170Vac~280Vac)±2%@UPS; (90Vac~280Vac)±2%@APL |
|
Frequency |
50Hz/60Hz (Auto detection) |
|
Efficiency |
>95% |
|
Conversion time (bypass and inverter) |
10ms (typical) |
|
Maximum bypass overload current |
60A |
|
Inverter Mode |
||
Output voltage waveform |
Pure sine wave |
|
Rated output power (VA)/(W) |
10000VA / 10000W |
|
Rated output voltage (Vac) |
230Vac |
|
Output voltage error |
±5% |
|
Output frequency range (Hz) |
50Hz±0.3Hz/60Hz±0.3Hz |
|
Maximum Efficiency |
>93% |
|
AC Charging |
||
Maximum charge current (can be set) |
150A |
|
Charge current error |
±5Adc |
|
Charge voltage range |
40 ~ 60Vdc |
|
PV Charging |
||
Number of MPPTs |
2 |
|
Maximum PV open circuit voltage |
500Vdc |
|
PV operating voltage range |
80-500Vdc |
|
MPPT voltage range |
90-450Vdc |
|
Maximum PV input power |
5000W+5000W |
|
Maximum PV input current |
22A+22A |
|
PV charging current range (can be set) |
0~150A |
|
Hybrid charging Max charger current specifications (AC charger+PV charger) |
||
PV charging current range (can be set) |
0~150A |
|
All-in-one machine specifications |
20Kwh + 10Kw |
30Kwh + 10Kw |
40Kwh + 10Kw |
45Kwh + 10Kw |
50Kwh + 10Kw |
||||
Battery Module Model * Number |
HS51200-10 * 2 |
HS51200-10 * 3 / LFP51300 * 2 |
HS51200-10 * 4 |
LFP51300 * 3 |
HS51200-10 * 5 |
||||
Energy |
20Kwh |
30Kwh |
40Kwh |
45Kwh |
50Kwh |
||||
Overall size |
690*590*565mm |
690*590*710/761mm |
690*590*855mm |
690*590*1004mm |
690*590*1000mm |
||||
Overall Weight |
≈212Kg |
≈297.5Kg / 277Kg |
≈383Kg |
≈395Kg |
≈468.5Kg |
||||
General specifications |
Parameter |
||||||||
Operating temperature range |
0°C to 55°C; > 45°C drop runs |
||||||||
Storage temperature range |
-10°C ~ 55°C |
||||||||
Humidity range |
5% to 95% (Conformal coating protection) |
||||||||
Heat dissipation |
Forced air cooling, variable speed of fan |
||||||||
Communication interface |
USB/RS485/WiFi(Optional)/ Dry node control |
||||||||
