SPECIFICATIONS

Brand Name: Trina

Cell Type: Mono Crystalline

Cell size: 182mmx182mm

Certificate: TUV/CE/IEC/ISO

Frame: Anodized Aluminium Alloy

Glass: 3.2mm,Anti-Reflection Coating,High Transmission,Tempered Glass

Model Number: TSM-NEG9RC.27,TSM-NEG9RC.27

No.of cells: 144

Panel Dimensions: 1762*1134*30 mm

Panel Efficiency: 22.0%,22.0%

Place of Origin: Anhui, China,Anhui-China

Solar cell: Half Cut Cell

Type: Half Cell,Bifacial,Double-glass,All Black,MWT,N-TYPE

Warranty: 10 Years

Module Type	NEG9RC27_415	NEG9RC27_420	NEG9RC27_425	NEG9RC27_430	NEG9RC27_435	NEG9RC27_440
Maximum Power (Pmax)	415Wp	420Wp	425Wp	430Wp	435Wp	440Wp
Maximum Power Voltage (Vmp)	42.1	42.5	42.9	43.2	43.6	44.0
Maximum Power Current (Imp)	9.86	9.89	9.92	9.96	9.99	10.01
Open-circuit Voltage (Voc)	50.1	50.5	50.9	51.4	50.4	51.8
Short-circuit Current (Isc)	10.50	10.53	10.56	10.59	10.64	10.67
Module Efficiency STC (%)	20.8%	21%	21.3%	21.5%	21.8%	22%
Operating Temperature(ȭ)	-40℃~+85℃
Maximum system voltage	DC1500V (IEC/UL)
Maximum series fuse rating	25A
Power tolerance	0~+3%
Temperature coefficients of Pmax	-0.34%/℃
Temperature coefficients of Voc	-0.25%/℃
Temperature coefficients of Isc	0.04%/℃
Nominal operating cell temperature (NOCT)	43±2℃

Half Cut Technology Under the same shadow condition, power loss of half-cell solar panel is less than that of full cell solar panel. Multi Busbar Technology MBB technology improves efficiency of modules, offers a better aesthetic appearance. PERC Technology The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.

100% Cells Sorting

Ensure Color and Power Difference.
Ensure high yields,consistent performance and durability.

100% EL Testing

Before and Following Lamination
Ensure "Zero" micro crack monitoring before final Inspection, Continuous line monitoring and video/photo record for each cell and
panel.

100% module Inspection

Before and After Lamination.
Most stringent acceptance criteria and tightest tolerance,
Intelligent alarm and stop mechanism in case of any deviation or errors.
