Yanyang Hardware BMS 8S 20A/40A/50A/60A/80A/100A Lifepo4 Lithium Battery EBike Electric Motorcycle FR-4 PCB with Passive Balance
Yanyang Hardware BMS 8S 20A/40A/50A/60A/80A/100A Lifepo4 Lithium Battery EBike Electric Motorcycle FR-4 PCB with Passive Balance
Pickup currently not available
SPECIFICATIONS
Application: 2 Wheel Motorcycle Ebike
Balance Current: Passive Balance
Base Material: FR4
Battery Type: Lifepo4 /Ternary
Board Size: 145*90*12 MM
Board Thickness: 10Z
Brand Name: Yanyang
Copper Thickness: 1.6MM
Cotinuous Charge / Discharge Current: 20A 40A 50A 60A 80A 100A
Functional Application: Circuit Protection
Material: FR-4
Min. Hole Size: 0.1MM
Min. Line Spacing: 0.1MM
Min. Line Width: 0.1MM
Model Number: YY-BPU12-MOS-8S
Number of Cells: 8S
OEM ODM: Support
Place of Origin: Hubei, China
Product name: Hardware BMS
Short Circuit Protection: Support
Surface Finishing: HASL Lead Free
Temperature Protection: Support
Type: electronic board
Warranty: One Year
Yanyang hardware bms lifepo4 8S 20A 40A 50A 60A 80A 100A bms for lithium battery ebike Electric motorcycle
We can also provide following Hardwae BMS Model :
4S 20A-100A
7S 20A-100A
8S 20A-100A
10S 20A-100A
13S 20A-100A
14S 20A-100A
15S 20A-100A
16S 20A-100A
17S 20A-100A
18S 20A-100A
19S 20A-100A
20S 20A-100A
Before order, you can inform us detailed Model requirement, we will arrange suitable model According to your requirement.
| Product | Hardware BMS |
| Model | YY-BPU12-MOS-8S |
| OEM ODM | Support |
| Battery Material | LiFePO4 / Ternary (Optional) |
| BMS Suitable For | Battery Pack |
| Short circuit Protection | Support |
| Size | 82*52*12 mm |
| Strings | 8S |
| Over Charge Protection | Support |
| Over Discharge Protection | Support |
