SPECIFICATIONS

Application: Computer

Brand Name: SZFYDOSH

Choice: yes

Condition: New

Dissipation Power: n/a

High-concerned chemical: none

Operating Temperature: n/a

Origin: Mainland China

Supply Voltage: n/a

Type: Module

is_customized: Yes

Specifications:

Brand new

Size: approx.50*30*2mm

Lampshift maximum discharge current: 15A

Instantaneous discharge current: 25A

Charging voltage: 25.5V

Charging current: 15A (MAX)

Overcharge detection voltage: 4.28 ± 0.05V

Overcharge protection delay: 0.1S

Overcharge release voltage: 4.08 ± 0.05V

Over discharge detection voltage: 2.55 ± 0.08V

Overdischarge detection delay: 0.1S

The overdischarge release voltage: 2.9 ± 0.1V

Overcurrent detection voltage: 150mV

Overcurrent detection delay: 9MS

Overcurrent protection current: 30 ± 3A

Overcurrent protection release condition: Disconnect the load

Short circuit detection delay: 250uS

Short circuit protection Release condition: disconnect negative open

Main circuit conduction resistance: ≤20mΩ

Working current: ≤30uA

Sleep current (battery over discharge) ≤10uA

Temperature range: -30 / + 80 °
