SPECIFICATIONS

Battery Type: LiFePO4

Brand Name: DELONGTOP

Cell Type: LiFePO4 Prismatic Cell

Communication Port: CAN,RS-232,RS485

Cycle life: 6500 Times

Dimension (L*W*H): 436*262*725mm/436*262*875mm

Energy: 10KWH/15KWH

Grid connection: Off grid,Hybrid grid

Keywords: Movable Solar LiFePO4 Battery 10KWH 15KWH

Model Number: LFP51200

Nominal Capacity: 200AH/300AH

Nominal Voltage: 48V/51.2V

OEM/ODM: Warmly Welcomed

Output Power Range: 5-10kW

Payment: Credit Card.Paypal.TT.Escrow.Western Union

Place of Origin: Guangdong, China

Protection Class: IP65

Shipping: By Sea / By Air

Size: 436*262*725mm/436*262*875mm

System Type: Wall-Mounted,Stackable,Rack-mounted

System Voltage: 51.2 V

Type: Split

Weight: 90KG

Trade Assurance

WHY CHOOSE DELONGTOP

1> Over 13 Years Lithium Battery Production Experiences Factory, R&D Department, Free for OEM & ODM

2> Alibaba SKA Golden Supplier: Three Alibaba Store: 13 Years DELONGBATTERY, 8 Years DELONGTOP, 3 Years DELONG FACTORY
3> Two Company Website: delongtop.com, delongbattery.com
4> Promise what we say and what we do

Details Images

Vertical Movable 48V 51.2V 200AH10KWH 300AH 15KWH LiFePO4 Battery

→Movable Type LiFePO4 Home Solar Energy Storage Battery Pack

→Large capability and long life for all high power output applications
→Low self-discharge and good discharge performance at low temperature
→Ultra reliable Lithium Iron Phosphate (LiFePO4) Battery Technology
→Environmentally friendly non-toxic, non-contaminating, no rare metal
→Easy to install and operate
→With movable wheels and communication cables and M8 connected cables
→With User Manual

48V/51.2V 200AH Vertical Movable LiFePO4 Battery

200AH Prismatic Cell 16S1P 10KWH

Built in LED Display, M8 Terminal, ON/OFF Switch, RS485 CAN Inverter Communication Port, RS232 PC Port, DIP Code.(Bule Tooth/ WiFi Customised Available)

With Wheels Easy to Move

With Communication Cable

With User Manual

48V/51.2V 200AH Vertical Movable LiFePO4 Battery

300AH Prismatic Cell 16S1P 15KWH

Built in LED Display, M8 Terminal, ON/OFF Switch, RS485 CAN Inverter Communication Port, RS232 PC Port, DIP Code.(Bule Tooth/ WiFi Customised Available)
With Wheels Easy to Move
With Communication Cable
With User Manual

Foucs on Solar Energy Storage System:

Our Vertical Movable LiFePO4 battery pack was specially developed for home solar energy storage system. The battery used the lightest prismatic cell and can be mounted on the floor or install on the wall.

48V(16S 51.2V) 200AH/300AH LiFePO4 Battery Floor Mounted supply the enough power to the home applications , and our battery meet the standard of most inverter and MPPT controller. If you are not sure, you can tell us the information of the inverter and controller you are using and we will custom the right battery to you.

Product Parameter

Vertical Movable 48V 51.2V 200AH10KWH 300AH 15KWH LiFePO4 Battery
Battery No.	LVM10			LVM15
Battery Pack	51.2V 200AH	51.2V 230AH	51.2V 280AH	51.2V 300AH
Nominal Voltage	51.2V
Nominal Capacity	200AH	230AH	280AH	300AH
Battery Energy	10.24KWH	11.77KWH	14.33KWH	15.36KWH
Charge Cut-Off	57.6V
Discharge Cut-Off	44.8V
Max. Charge Current	100A
Max. Disharge Current	200A
Recommended Load	5-10KW
Cell Type	LiFePO4 Prismatic Cell
Terminal	M8
Case Material	Metal Case
Communication Mode	RS485/CAN(Bule Tooth/ WiFi Customised Available)
Charge Temperature	0~50℃
Discharge Temperature	-10~55℃
Cycle Life	6500+ Times
Design Life	12+ Years
Color	White
Weight	90KG	92KG	108KG	110KG
Dimension	436*262*725mm			436*262*875mm
Assembly Method	Movable with Wheels
WHAT WE CAN DO MORE
Warranty	10 YEARS WARRANTY
Battery Standard	CE, UL, IEC, RoHS, MSDS, UN38.3

Compatible Solar Partner

Compatible with Most of Popular Solar Inverters

Our BMS is a complete set of communication functions, supporting RS485, RS232 and CAN-BUS communication protocols. We can also customize the communication content according to the information which customers provide. Customers can through the host computer software to monitor the batteries, and check the working status of each cells and set specific parameters on the computer.

Advantages of DELONGTOP

10 YEARS WARRANTY

We offer 10 years truly warranty to provide after-sale service and technology support.

1> Re-sending new battery within 1st year if something is wrong with the quality of the product

2> Provide purchase accessories free within 2nd~5th years warranty

3> Provide technology support free within 6th~10th years warranty

WHAT BATTERY CELL WE USE:

As a 10-year-old store engaged in the battery business, we are responsible for our customers and our brand. Using only A grade cells, the cycle life can up to 6000-8000 times: 10AH/ 25AH/ 50AH/ 100AH/ 200AH / 300AH / 560AH/ 600AH...

1> Our batteries are the primary source of supply from the original cells manufacturer, battery cells are paired and distributed before outgoing, and can be assembled directly.

2> Through a number of certification and testing, quality assurance.

3> There are two types of pouch cells and prismatic cells. The pouch cells: lighter, cheaper, and easy to customized in special sizes. The prismatic cells: not easily deformed , stable performance, mature market, more popular at present.

MAINLY MARKET AND CUSTOMERS' FEEDBACK

Our batteries are all over the world, the main markets are North America, Europe, Australia, Middle East and Southeast Asia.

Solar home energy storage LiFePO4 battery Stackable, Wall Mounted- Rack Mounted, Movable series is especially suitable for use in countries and regions where there is a shortage of mains electricity, which is environmentally friendly and safe.

"Quality is our Culture", our batteries are worked well and received many good comments:

Related Products

High Voltage 102.4V 100AH Module Stackable LiFePO4 Battery

204.8V 100AH 20.48KWH

307.2V 100AH 30.72KWH
409.6V 100AH 40.96KWH
512V 100AH 51.2KWH
614.4V 100AH 61.44KWH

High Voltage 102.4V 157AH Module Stackable LiFePO4 Battery

204.8V 157AH 32.15KWH

307.2V 157AH 48.23KWH

409.6V 157AH 64.3KWH
512V 157AH 80.38KWH
614.4V 157AH 96.39KWH

High Voltage 102.4V 16KWH 30KWH Module LiFePO4 Battery Cabinet

307.2V 280AH 86KWH

409.6V 280AH 114.68KWH
512V 280AH 143.36KWH
614.4V 280AH 172.03KWH

Certifications

FAQ

Q1: What are there included for a battery or pack , may I buy charger from you?

A1: Battery case, BMS, battery pack, can buy customised connector, charger

Q2: How long frequency does recharge the battery?

A2: Usually per 2 months to recharge the battery pack , to charge full the battery depends on the charger current you use. 20A charger can charge full for 12V 100Ah battery in 5 hours, fast charger 50A in 2 hours.

Q3: What's the sample lead time, and bulk order delivery. How long I can get it?
A3: Fast delivery: If small quantity, can be finished in 3-5 days days after payment, bulk in 10-25 days depends on the quantity
Shipping: sample order or small battery packs, we can ship by express through Fedex, UPS, TNT etc. If whole parcel over 50KG, can ship by air or by sea, sea shipping is more cheaper. Customer can tell your nearest airport name and sea port name for sales person to check the best option for you.

Q4. What is your warranty?

A4: We offer 10 years warranty for different situation. We ensure at least 6500 cycle life for the LiFePO4 battery pack, You can use it for at least 10 years for normal 1 time charge and discharge everyday.

Q5: Can I customize the size of battery?

A5: Of course yes if yourquantity MOQ workable.

Q6. Can we put different LiFePO4 battery pack in parallel or series by ourself?

A6: Yes. The battery can be put in parallel or series by customers. But there are few tips we need to pay attention;

1> Make sure the voltage of each battery are same before put inparallel. If they are not same, charge them to
the same rate.

2> Don't not put discharged battery and undischarged battery in parallel. This may reduce the capacity of the whole
battery pack.

3> Advise us the target capacity of the whole pack if you would like to put them in series. We will choose the
suitable BMS for each battery.

4> If you are not professional in parallel and series batteries, please don't handle the battery by yourself. It may cause danger and hurt the cycle life of battery.

Q7. Can we use it for car engine?

A7: Yes, our battery pack include BMS, you can use it for low speed car only or aux. power for standard car. Do not use it for standard car directly, that will need more complex design BMS for the pack.
