Tycorun Super Capacitor 12v Lifepo4 Battery 50ah for Electric Car/drone/motor Battery Motorcycle
Tycorun Super Capacitor 12v Lifepo4 Battery 50ah for Electric Car/drone/motor Battery Motorcycle
Pickup currently not available
SPECIFICATIONS
Anode Material: LFP
Application: Home Appliances,Boats,Golf Carts,SUBMARINES,Electric Bicycles/Scooters,electric vehicles,Electric Wheelchairs,Electric Power Systems,Solar Energy Storage Systems,Uninterruptible Power Supplies
BMS: Built-in BMS Protection
Battery Type: Liquid
Battery type: Lifepo4/lithium Battery
Brand Name: Tycorun
Cathode Materials: LiFePO4
Cycle Life: 3000 cycles
Dimension (L*W*H): 229*138*208mm
Features: Deep Cycle Battery
Keyword: batterie lithium ion 12v 50ah
Max Load Quantity(cells): 16
Model Number: TP12200
Name: lifepo4 battery pack
Nominal Capacity: 50ah
Nominal Voltage: 12.8 Volt
Operating Temperature(℃): -20℃~55℃
Place of Origin: Guangdong, China
The charging ratio: 0.2C(Standard),0.7C(Max, 25℃)
The discharge rate: 0.5C(Standard),1C(Max, 25℃)
Weight: 6kg
Modal |
TC1206 |
TC1220 |
TC1250 |
TC12100 |
TC12200 |
|||||
Electrical Characteristics |
||||||||||
Rated voltage |
12.8V |
12.8V |
12.8V |
12.8V |
12.8V |
|||||
Rated capacity |
6Ah@0.2C |
20Ah@0.2C |
50Ah@0.2C |
100Ah@0.2C |
200Ah@0.2C |
|||||
Rated power |
76.8Wh |
256Wh |
640Wh |
1280Wh |
2560Wh |
|||||
Internal Resistance |
150≤mΩ |
80≤mΩ |
60≤mΩ |
40≤mΩ |
30≤mΩ |
|||||
Cycle Life |
>2000 Cycles @ 0.2C Charge/Discharge at 100%DOD,End of Life 80% Capacity |
|||||||||
Months Self Discharge |
≤3.5% per month at 25℃ |
|||||||||
Standard Charging |
||||||||||
Charge Voltage |
14.6±0.2V |
14.6±0.2V |
14.6±0.2V |
14.6±0.2V |
14.6±0.2V |
|||||
Charge Mode(CC/CV) |
CC/CV |
CC/CV |
CC/CV |
CC/CV |
CC/CV |
|||||
Charging electricity |
1.2A |
4A |
10A |
20A |
20A |
|||||
Max charging electricity |
6A |
20A |
50A |
100A |
100A |
|||||
Standard Discharging |
||||||||||
Discharging electricity |
6A |
20A |
50A |
100A |
100A |
|||||
Max. Continuous electricity |
9A |
30A |
75A |
150A |
150A |
|||||
Max.Pulse Current |
18A(<3S） |
60A(<3S） |
150A(<3S） |
300A(<3S） |
300A(<3S） |
|||||
Discharge Cut-off Voltage |
10.8V |
10.8V |
10.8V |
10.8V |
10.8V |
|||||
Operating Condition |
||||||||||
Charge Temperature |
0℃~45℃ |
|||||||||
Discharge Temperature |
-20℃~60℃ |
|||||||||
Storage Temperature |
0℃~45℃ |
|||||||||
Water Dust Resistance |
IP65 |
|||||||||
Structure |
||||||||||
Plastic Case |
ABS |
|||||||||
Dimension(L*W*H) mm |
90*70*101 |
181*77*167 |
229*138*208 |
330*173*220 |
522*240*218 |
|||||
Weight |
0.7Kg |
2.6Kg |
6Kg |
12.5Kg |
25Kg |
|||||
Terminal |
T2 |
M5 |
M6 |
M8 |
M8 |
|||||
