SPECIFICATIONS

Application: Solar Energy Storage Systems,Golf Carts,Electric Power Systems,Electric Forklifts

Battery Type: Liquid

Battery type: LiFePO4

Brand Name: Lusen

Capacity: 314ah

Cathode Materials: LiFePO4

Cycle Life: 6000 cycles

Dimension (L*W*H): 385*194*248mm

Dimension(W*H*D): 385*194*248mm

Max Load Quantity(cells): 4

Model Number: 12v 314ah

Operating Temperature(℃): Charging: 0~45℃/Discharging: -20~60℃

Operating voltage range: 10V~14.6V

Place of Origin: Shandong, China

Protection rating: IP20

Rated charging/discharging current: 60A/200A/314A

Rated charging/discharging power: 768W/2560W

Rated voltage: 12v

Total energy: 3840Wh

Weight: 25.5kg,17.5kg

	12V100Ah	12V200Ah	12V300Ah	24V100Ah	24V200Ah	24V300Ah
Battery type	LiFePO4	LiFePO4	LiFePO4	LiFePO4	LiFePO4	LiFePO4
Total energy	1280Wh	2560Wh	3840Wh	2560Wh	5120Wh	7680Wh
Rated voltage	12.8V	12.8V	12.8V	25.6V	25.6V	25.6V
Capacity	105Ah	200Ah	300Ah	100Ah	200Ah	300Ah
Operating voltage range	10V~14.6V	10V~14.6V	10V~14.6V	20V~29.2V	20V~29.2V	20V~29.2V
Rated charging/discharging power	256W/640W	512W/1280W	768W/2560W	512W/1280W	1024W/2560W	1536W/5120W
Rated charging/discharging current	20A/50A	40A/100A	60A/200A	20A/50A	40A/100A	60A/200A
Dimension(W*H*D)	260*168*212mm	384*194*248mm	385*194*248mm	384*194*248mm	520*269*220mm	520*269*220mm
Weight	10kg	17.5kg	25.5kg	17.5kg	35kg	52kg
Protection rating	IP20	IP20	IP20	IP20	IP20	IP20

Q: Are you manufacturer or trading company? A：We are a large enterprise that integrates research and development, production, and sales. Q: How does your factory carry out quality control? A: We attach great importance to quality control.Every part of our products has its own quality control. Q: what can you buy from us? A:Batteries, battery cells, inverters, lead to lithium conversion, solar panels, etc Q: What is the delivery time for your products? A: Once we promise the delivery time, we will try our best to do so. Special procedures such as emergency inventory will be used to maintain your uninterrupted supply of the products. Q: What about the after sale service? A：We provide after-sales service for customers, including replacing new products, replacing circuit boards, etc.
