SPECIFICATIONS

Application: Home and outdoor energy storage / Solar Storage Battery

Battery Type: LiFePo4 or Lithium

Battery type: Brand Grade A Cell Battery

Brand Name: Lithtech

Capacity: 100Ah 200Ah 280Ah 314Ah OEM 400AH 500AH

Certification: IEC 62619 / CE / UN38.3 / MSDS / uI

Communication Port: CAN,RS-232,RS485,Wifi,Bluetooth

Cycle life: 8000 Cycle

Dimension (L*W*H): 600*500*167(±5mm)

Grid connection: Off grid,Hybrid grid,on grid

Inverter Matched: Deye Growatt LUXPOWER MEGAREVO Victron SMA and other

Keywords: Home Inverter Solar lifepo4 lithium Battery

Model Number: HP1500K

OEM/ODM: Yes

Output Power Range: 5-10kW

Place of Origin: Guangdong, China

Product name: Power Wall 5kwh 10kwh 15kwh lifepo4 lithium battery

Protection Class: IP55

System Type: Wall-Mounted

System Voltage: 51.2 V

Warranty: 10 Years max

Weight: 53kg

European German Poland American Romanian Philippine Vietnam Iraqi and China Warehouses In Stock

Products Description

ISO9001 MDSD UN38.8 CE UL1973 UL9540 UL9540A RoHS IEC62619 EMC CEC MSDS and Other Certificates

PERFORMANCE SPECIFICATIONS
Model	TR4000WX	TR6000WX	TR8000WX	TR8500WX
Rating Voltage	51.2V	51.2V	51.2V	51.2V
Cell model/Configuration	3.2V100Ah/16S1P	3.2V100Ah/16S2P	3.2V280Ah/16S1P	3.2V314Ah/16S1P
Rating Capacity	100Ah	200Ah	280Ah	314Ah
Rated Energy(kWh)	5.12kWh	10.24kWh	14.34kWh	16.07kWh
Max.Charge/Discharge Current(A)	100A	200A	200A	200A
Voltage Range(Vdc)	44.8V~58.4V
Scalability	Up to 15 parallel
Communication	CAN/RS485/RS232/Bluetooth /WIFI
Cycle Life	≥8000Cydes@25℃
Design Life	≥15Years(25°C)
display usage	LCD color touch display
MECHANICAL SPECIFICATIONS
Weight(Net/Gross)(KG)	53kg	99.5kg	132.5kg	134kg
Dimension(W/D/H)(mm)	600*500*167mm	850x650x167mm	850x650x245mm	850x650x245mm
Installation Mode	Wall Mounnted
IP Grade	IP54 (optional)
SECURITY AND CERTIFICATION
Safety(Pack）	UN38.3,MSDS,IEC62619(CB),CE-EMC
Safety(Cell)	UN38.3,MSDS,IEC62619,CE,UL1973,UL2054
Protection	Smart BMS,Breake and Aerogel Fireproofing（optional）
ENVIRONMENTAL SPECIFICATIONS
Operating Temperature(°C)	Charge 0℃~65℃; Discharge -20℃~65℃
Altitude(m)	≤3000m
Humidity	≤95%(Non-condensing)

Delivery Time

Item	1-50PCS	50-100pcs	1000+pcs	10000+pcs
Need Dangerous Goods Transport Certificate	5days	10-15days	20days	30days
Not Need Dangerous Goods Transport Certificate	5days	7-15days	15-20days	30days

After Sales Response Time

Beijing Time 9:00-22:00	Weekday	Saturday	Sunday	Chinese Statutory Holidays
Salesman GFL	≤1 Hour	≤2 Hour	≤ 4 Hour	/
CEO GFL	≤1 Hour	≤2 Hour	≤ 4 Hour	≤1 Day

Why Choose Us

Shenzhen Lithtech Energy Co., Ltd. is a premier lithium battery manufacturer with 20 years of industry experience and its own factory, specializing in OEM and ODM services as a professional battery maker offering 48-hour sampling and 5-day delivery with 24-hour customer support, supported by 9 overseas warehouses for fast delivery including European, German, Polish, American,Romanian, Philippine, Vietnamese, Iraqi, and China main warehouses, mainly dealing in home energy storage, 48V/51.2V 100ah 200ah 300ah 280ah 314ah LiFePO4 lithium battery, solar batteries, 12V/24V 50ah 100ah 120ah 150ah 200ah 314ah 400ah LiFePO4 lithium battery, BESS, ESS, outdoor battery cabinets, rack batteries, wall-mounted batteries, commercial and industrial energy storage,and energy storage systems, holding major certificates including ISO9001 MDSD UN38.8 CE UL1973 UL9540 UL9540A RoHS IEC62619 EMC CEC MSDS and Other Certificates, having served over 10 million customers across more than 100 countries and providing energy services to Fortune 500 companies.

Regional agent

FAQ

Q:How long is the delivery time of your products? A:Overseas Warehousing: Up to 3 days delivery，China:Usually about 30days .

Q:What kind of certificates your products have?
A:LITHTECH ENERGY battery products have acquired CE,UL,UN38.3,MSDS,CEC,RoHS and other certificates, which is able to satisfy most country’s importing requirements. Q:Can you supply OEM &ODM service ? A:Yes, but there is a minimum order quantity required.

Q:Can you ship your battery products by sea or by air ?
A:We have long-term cooperated forwarders who are professional at battery shipment.

Q:How long is the warranty?
A:Our warranty is from 5-10 years.

Q:How do you provide after-sales service?
A:We have overseas branches can provide repair and replacement.

Q：how much for sample ?
A：We will calculate the best competitive price for your sample.To quote you best price, could you pls let me know what capacity and purchasing quantity are you looking for?

Q: I'm interested in this product. Do you have MOQ?
A:Glad to know that you are interested in our LifePo4 battery, For standard models, we have ready stock and no MOQ. If you have some customization needs, share with us and we can check for you.

Q: Do you have Europe warehouse, how much for one battery to my address?
A: Yes we have Europe warehouses, located in Germany, Poland, Romania(on going), to check door to door price for you,
please leave your address with zip code information,we will check at work time, thank you.

Q:We are determined to add battery into our product list, could you send me your price list?
A:We have distributors globally, to protect their rights, could you please let me know your target market and website/business scope etc? so we can check and proceed, thank you.

Q：Are your batteries compatiblie with Deye and other inverter?
A: Our batteries compatible with most major inverter in the market,which on the list of Solis, Deye, Sinexcel etc.

Q. Are your energy storage products manufactured in your own factory?
A:Yes! We have a 100% owned factory and offer direct factory sales. This ensures full control over product quality from production to delivery, with no middlemen involved.

Q:What makes your prices more competitive than other suppliers?
A: Our core price advantage comes from direct factory sales with no intermediaries. As we own our manufacturing facility, we cut out extra costs and pass the savings to you, providing the most competitive prices in the market.

Q:Do you have an in-house R&D team?
A:Absolutely. We have a dedicated R&D center team that focuses on continuous product innovation and optimization. This allows us to keep up with the latest energy storage technologies and tailor solutions to meet diverse customer needs.

Q:Can I get fast product delivery and local support in the EU?
A:Definitely. We’ve built a global distribution network and overseas warehouses in Germany to serving entire EU
with dropshopping service for a long term and stalble supply.

Q: How long does it take to deliver products after an order is placed?
A: Depends on the products you looking for, if you based in EU inquiring for our stock model, a fast delivery within 3-7
days can reach your place. For a C&I BESS system, it is refer with our standard system, we may have regular stock to support with a fast delivery. For customized order, a lead time around 10-14 weeeks depends on different projects case
