SPECIFICATIONS

Application: lifepo4 LTO Ternary lithium battery LI-ION,LiFeFo4 LTO Ternary Lithium Battery

Brand Name: JKBMS(jikong bms)

Certificates: CE ISO9001 FCC ROHS UL

Copper Thickness: 2 OZ

Functional Application: Energy Storage

Functional application: BLUETOOTH RS485 CANBUS HEAT PARALLEL

Model Number: JK-BD6A20S6P

Operating System: Android 9.0,Android 11.0,Android 7.1,ubuntu 20.04,debian 10,Android 6.0,Android 8.0

Place of Origin: Sichuan, China,Chengdu China

RAM: 64 GB

Service: OEM ODM

Strings: 8-20S

Supplier Type: manufacturer Wholesale & Retail

Type: power bank pcba BMS

active balancing current: 0.6A

continuous charge-discharge current: 60A

firmware version: THE latest

peak current: 120A

Product Paramenters

NTC quantity    1 built-in	Battery capacity calculation
Short circuit protection	High precision voltage current acquisition
Display interface	Charge over voltage current protection
Discharge Charge over temperature protection	Discharge under voltage protection
GPS BLUETOOTH  interface	Discharge over current protection
Operating	-30-70℃C temperature
battery type	TLB battery type LFP/ LTO
battery type	ios/Android HarmonyOS/PC

Details Images

Our Advantages

Customer Photos

Product packaging

FAQ

1. Why can't the battery discharge?

Low voltage triggers protection and stops discharging. 2. The protection boaromalfunctions
or is damaged.3.Incorrect wiring or line interruption.

2. Why can't the battery be fully charged when charging?
The charger is faulty or the wiring is incorrect. 2. The protection status has notbeen lifted.

3. How to deal with faults in the protection board?
Use a multimeter to test the battery voltage and the output of the protection ic

4. Mayl ask if samples are supported?
Welcome to purchase samples. The sample fee will be refunded based on thefuture cooperation situation.

5. What are your payment terms?
We accept telegraphic transfer and cash payment, etc. Everything can benegotiated. Available payment methods: visa, master card,T/T,PayPal. APPLEPAY,GOOGLE PAY,GC real-time bank transfer. RMB.

6. Regarding logistics
You can choose your own logistics method, and the freight will be automaticallyconverted, or you can use the logistics method we recommend
